Traverse Length 54”
Cutter plate to table 22”
Motor 2 HP 220VAC 3 Phase 7 AMP
Power Requirements 220 volt 3 phase (has single phase converter on it also)
Traverse Motor 180VDC Infinitely Variable
Cutting Speed 1150 RPM (300-1750 with Speed Control)
Cutter Plate Diameter 15 1/2”
Floor Space Requirement 80”L x 38”D x 84”H
Shipping Weight 2700 Pounds
Changeover from heads to V-blocks in less than 1
minute
WATCH A DEMO ON YOUTUBE !! CLICK LINK BELOW
https://www.youtube.com/watch?v=BL1bQqaS6Jk
800-841-5405, 712-852-4627
