DCM’s MPI 4830B is a specialized vertical format unit developed for production testing of blocks and other bulky workpieces. This vertical format magnetic particle inspection system features a convenient rotary table and powered coil traverse so you can easily inspect the part. An optional head fixture makes this machine the logical choice for Production Engine Engine, Rebuilders and Performance Engine.
SPECIFICATIONS
Coil Travel 42″
Coil 30″ Diameter, 10,000 ampere turn
Power Supply Output 3000 amp AC
Standard Electrical Requirements 230 V 1ph 100 FLA
Optional Electrical Requirements 460 V 1ph 50 FLA
Floor Space required 46″ x 78″
Shipping weight 1200 lbs.
Max part weight 800 lbs
APPLICATIONS
Automotive and Heavy Duty Industrial Crankshafts
Connecting rods
Cylinder Heads
Ferrous Industrial Parts
Aircraft Components
NEW THESE ARE AROUND 90K DOLLARS
800-841-5405, 712-852-4627
