CAPACITY
Valve stem diameter range:
• minimum: 4 mm (5/32")
• maximum: 14.3 mm (9/16")
Valve head diameter range:
• minimum: 13 mm (1/2")
• maximum: 112 mm (4")
Valve overall length:
• minimum: 70 mm (2" 3/4)
• maximum: 255 mm (10")
Grinding wheel diameter:
• 200 mm / 8"
Grinding wheel width:
• 10 mm / 0.4"
Cup wheel diameter:
• 100 mm / 4"
Wheel head motor:
• Speed 3000 RPM
Valve driving motor:
• Speed range 160 to 830 RPM
Coolant capacity:
• 4 liters / 1 US gallon
Grinding angle range:
• 0° to 47°
ELECTRIC AND AIR SUPPLY
• Voltage 220 V ( ± 10 % ) 50 Hz, 16 ampers
• Air supply 6 bars; 6 m³/hour
DIMENSIONS AND WEIGHT
• Weight 150 Kgs / 330 lbs
